High Nd:YAG output power: 7W UV at 10kHz (700µJ) . 10W Green at 10kHz (1mJ).

⤓ DXG-AC Series Datasheet

Features

• All-in-one (AIO), air-cooled form factor
• Total pulse control
• Pioneering intracavity harmonic technology

Overview

The DXG-AC Series Lasers are Nd: YAG nanosecond Laser Series, offering a compact, industrial-grade solution with high pulse energy and fast repetition rates. The combination of short pulse duration and high pulse energy in the 5 to 15kHz domain make the DXG Series ideal for demanding applications requiring high material removal rates with precision beam quality.
Available as fully air-cooled or optional base plate cooled using a passive radiator or active chiller water cooling, the DXG-AC lasers provide complete flexibility for OEM integration. A full suite of pulse frequency and pulse energy controls also ensures that the laser output is tailored precisely to a variety of applications

⤓ DXG-AC Series Datasheet

High output power: 10W UV at 50kHz. 20W Green at 70kHz.

⤓ DX-AC Series Datasheet

Features

• All-in-one (AIO), air-cooled form factor
• Total pulse control
• Pioneering intracavity harmonic technology

Overview

The Photonics Industries DX-AC Series offers a compelling solution for applications from ultraviolet marking, specialty material micromachining, and additive manufacturing.

These fully air-cooled lasers deliver industry-leading performance in beam quality, stability, and precision control. This is achieved through Photonics Industries’ pioneering intracavity UV and Green harmonic technology, ensuring higher reliability and lower COO. The DX-AC Series achieves this high performance in a remarkably compact package. The all-in-one (AIO) design integrates all electronics within the laser head, eliminating the need for a separate controller or utility module and minimizing footprint. The laser is “plug-and-play” with a simple 15V power supply for ease-of-integration.

⤓ DX-AC Series Datasheet

High output power: 50W UV at 50kHz (1mJ). 80W Green at 100kHz (0.8mJ). < 25ns.

⤓ DX-SP Series Datasheet

Features

• High single pulse energy – 1mJ
• Pioneered intracavity harmonics – Excellent beam quality, low COO
• All-in-one (AIO) for easy integration

Overview

Photonics Industries’ DX Series short pulse nanosecond lasers provide industrial systems with the most ideal compact form factor, short pulse width (down to ~10 ns), high power, high repetition rate (up to 1 MHz) Q-switched DPSS laser for high production throughput and precision quality. Specially patented intracavity harmonic generation, with no damaging indexing on the harmonic crystals, allows for higher performance and higher reliability, fulfilling demanding production criteria.

⤓ DX-SP Series Datasheet

High Nd:YAG output power: 30W UV at 10kHz (3mJ). 40W Green at 10kHz (4mJ). <~25ns.

⤓ DXG Series Datasheet

Features

• High single pulse energy – 4mJ @ 10kHz
• Pioneered intracavity harmonics – Excellent beam quality, low COO
• All-in-one (AIO) for easy integration

Overview

The DXG Series Lasers are Nd: YAG nanosecond Laser Series, offering a compact, industrial-grade solution with high pulse energy and fast repetition rates. The combination of short pulse duration and high pulse energy in the 5 to 15kHz domain make the DXG Series ideal for demanding applications requiring high material removal rates with precision beam quality.
Available in a compact, water-cooled format, the DXG lasers provide complete flexibility for OEM integration. A full suite of pulse frequency and pulse energy controls also ensures that the laser output is tailored precisely to a variety of applications

⤓ DXG Series Datasheet

Long pulse, high Nd:YAG output power: Up to 30W (3mJ) Green, @9 kHz, ~80ns

⤓ DXG LP Series Datasheet

Features

• Unique in market for long, high energy nanosecond pulses
• Pioneered intracavity harmonics – Excellent beam quality, low COO
• All-in-one (AIO) for easy integration

Overview

The DXG Series Long Pulse Nd:YAG lasers offer a robust, industrial-grade solution for high-precision material processing. With nanosecond pulse durations and high pulse energies, these lasers excel in applications such as diamond cutting, Silicon carbide annealing, and thermal processing, where controlled heat input minimizes thermal damage while ensuring high-quality results. This combination makes the DXG Series particularly suited for demanding industries like aerospace, electronics, and advanced manufacturing.
Designed in a compact, water-cooled format, the DXG lasers are optimized for seamless OEM integration. Comprehensive pulse frequency and energy controls allow users to tailor the laser output to specific application needs. By bridging the gap between short-pulse and continuous-wave laser technologies, the DXG Series addresses the growing demand for precision, reliability, and versatility in modern material processing.

⤓ DXG LP Series Datasheet

Long pulse, high output power: >30W UV, 12~300ns. 50W Green, 65~340 ns.

⤓ DX-LP Series Datasheet

Features

• Unique in market for long, high energy nanosecond pulses
• Pioneered intracavity harmonics – Excellent beam quality, low COO
• All-in-one (AIO) for easy integration

Overview

Photonics Industries’ DX Series long pulse nanosecond lasers provide industrial systems with a slim form factor, longer pulse width (up to ~340 ns), high repetition rate (up to 200 kHz) Q-switched DPSS laser for long pulse, thermal-focused, and deeper depth microprocessing. Specially patented intracavity harmonic generation, with no damaging indexing on the harmonic crystals, allows for higher performance and higher reliability, fulfilling demanding production criteria.

⤓ DX-LP Series Datasheet

High pulse energy, 1mJ UV at 1kHz, 1.5mJ Green at 1kHz.

⤓ DC YLF Series Datasheet

Photonics Industries’ DC Series Nd:YLF Nanosecond Lasers combine ideal mJ pulse energy levels with high kHz repetition rates (single shot to 10 kHz), while maintaining short pulse widths, all within a compact, air-cooled form factor.

Features

• Industry-leading intracavity Nd:YLF technology for 30+ years
• Reliable, proven, all-in-one (AIO) air-cooled
• Ideal for FPD and high energy applications

⤓ DC YLF Series Datasheet

TEM₀₀ pulse energy: 35 mJ at 1 kHz, 527 nm.

⤓ DX YLF Series Datasheet

Features

• Highest pulse energy at 1kHz with TEM₀₀ beam mode commercially available
• Compact form factor for easy integration
• Industry-leading intracavity Nd:YLF technology for 30+ years

⤓ DX YLF Series Datasheet

Exceptional high pulse energy UV laser: Up to 50 mJ at 1 kHz, Nd:YLF

DM1-351-20| DM1-351-30 | DM1-351-50

DM UV Series Multimode Nanosecond Lasers Brochure

Features

• Exceptional high pulse energy UV laser:
  Up to 50 mJ, 351 nm (Nd:YLF)
• Exceptional repetition rate control:
  Single shot up to 5 kHz
• Long nanosecond pulse width
  Up to ~100 ns

Overview

Photonics Industries’ DM UV Series 351 nm nanosecond lasers combine remarkably high pulse energies (up to 50 mJ) within a simple, rugged, and efficient form factor. Long nanosecond pulse widths (~100ns) and high pulse repetition rate (0 – 5 kHz) offer an ideal solution for many applications requiring high pulse energy, such as in semiconductor manufacturing. The DM UV is the most compact and highest pulse energy UV (351 nm) industrial nanosecond laser source, leveraging Photonics Industries pioneering intracavity harmonics and power-scaling technologies.

DM UV Series Multimode Nanosecond Lasers Brochure

High pulse energy, TEM₀₀ output, with low pulse widths: Up to 50 mJ at 6-10 ns pulse width range

DP5 | DP20 | DP50 | DP1k

DP Series High Pulse Energy Nanosecond Lasers Brochure

Features

• Extremely efficient with 5X to 10X lower heat vs. the competition: 5% to 10% conversion from wall power.
• Small, air-cooled, all-in-one (AIO) form factor
• Multiwavelength Selectable (MWS) & Multiwavelength Blended (MWB) options: Select and/or blend IR, Green, UV, & DUV
• Continuously variable pulse repetition rates: 1 Hz to 100 Hz, or up to 1 kHz
• Superior beam pointing stability: < 25 µrad
• Total Pulse Control for ideal integration into systems: Duty Control, PEC (Power or Pulse Energy Control)
• Reliable, low COO, non-consumable design: Patented intracavity harmonic UV & Green generation

Overview

Photonics Industries’ DP Series diode-pumped solid-state (DPSS), Q-Switched, high energy, short pulse width lasers combine up to 20mJ pulse energy levels, TEM00 output, and exceptional power efficiency with 10X lower heat load vs. closest competitors. With the ability to select and/or blend multiple wavelengths, the DP Series is an ideal, compact air-cooled package for industrial applications, from intra-marking glass, to repairing displays. Scientific applications also benefit where the high pulse energies align well for atomic excitation research or spectroscopy systems.

DP Series High Pulse Energy Nanosecond Lasers Brochure

Patented highest pulse energy green laser from a single resonator: Up to 100 mJ, Nd:YLF; Up to 200 W, Nd:YAG

High Pulse Energy (Nd:YLF, 527nm)

DM1-527-20 | DM1-527-30 | DM1-527-40 | DM1-527-50 | DM1-527-60 | DM1-527-100

DM Series Nd:YLF Laser Brochure

High Power (Nd:YAG, 532nm)

DM1-532-60 | DM1-532-100 | DM1-532-150 | DM1-532-200

DM Series Nd:YAG Laser Brochure

Features

• Two fully independent lasers, integrated into a Dual Head* configuration available (see DM2 Series Dual Head brochure): Up to 200 mJ, Nd:YLF; Up to 400 W, Nd:YAG
• Exceptional repetition rate control: Single shot up to 10 kHz, Nd:YLF; 1 to 50 kHz, Nd:YAG
• Excellent pulse stability: < 0.5% rms
• Proprietary Twin Pulse mode† option: Generation of pulses in pairs with a calibrated pulse energy ratio. Controllable pulse separation down to 1 µs (< 1 µs for Dual Head)
• TEM00 beam option available. Contact us.
• Unmatched reliability: < 1% service call requests within the warranty period in the latest 24-month statistics

*All models can be configured in a Dual Head. Please see DM2 Series Dual Head brochure.
† PI’s patented twin pulse mode provides double pulses from a single trigger signal from the single laser head. Energy ratio of the twin pulses and pulse separation between the twin pulses is user programmable

Overview

Photonics Industries’ DM1 Series Nd:YLF and Nd:YAG green nanosecond lasers combine remarkably high pulse energies (up to 100 mJ) or high average powers (up to 200 W) with a simple, rugged, and efficient form factor, all from one fully independent laser resonator. Dual Head configurations can go up to 200 mJ of pulse energy or up to 400 W of power. The proprietary single laser resonator design[1] ideally fulfills the needs of both research and industry, from PIV research, to providing the necessary high energy for laser thermal processing or annealing applications in an industrial, compact form factor.
[1] US Patents #7,346,092 Diode side pumped high pulse energy Nd:YLF lasers, #7,082,149 High power diode side pumped solid state laser

Technologically Superior

Its technological superiority and high reliability has been verified by less than 1% service call request during the warranty period in the latest 24 months statistics.  For even higher pulse energy or sub microsecond pulse separation PIV applications, each of these models can be built into a dual head laser which will produce twice as much pulse energy as its single head counterpart (see DM2 Series Dual Head brochure).

Optimally Compact and Highly Reliable

• Improved, more compact form factor on the laser head.
• Integrated driver into the laser head, improving performance that would have otherwise been degraded when transduced over the umbilical.  All controls are now operated by a software GUI via a RS232 connection from the laser head to a computer—a plug and play, quick start functionality highly beneficial to the user.
• Legacy model controllers are now simply a power supply, with an emergency off button, clearly visible in any event that may require such an operation.  With a remarkably small form factor (at 2U) and a 19” rack-mount option, the user has the utmost versatility.
• For the Dual Head option, the adjustable turning mirrors are now adjusted via the software GUI rather than through manual adjustment.

Patented highest pulse energy green laser in the dual head regime: Up to 200 mJ, Nd:YLF; Up to 400 W, Nd:YAG

High Pulse Energy (Nd:YLF, 527nm)

DM2-527-20 | DM2-527-30 | DM2-527-40 | DM2-527-50 | DM2-527-60

DM2-527-100

High Power (Nd:YAG, 532nm)

DM2-532-60 | DM2-532-100 | DM2-532-150 | DM2-532-200

DM Dual Head Series Nd:YLF & Nd:YAG Nanosecond Lasers Brochure

Features

• Exceptional repetition rate control: Single shot up to 10 kHz, Nd:YLF; 1 to 50 kHz, Nd:YAG; Option up to 15 kHz available for Nd:YLF
• Excellent pulse stability: < 0.5% rms
• Proprietary Twin Pulse mode option for Quad Pulse in the Dual Head configuration: Generation of up to 4 pulses from a single trigger signal. Controllable pulse separation down to < 1 µs for Dual Head.
• TEM00 beam option available. Contact us.
• Unmatched reliability: < 1% service call requests within the warranty period in the latest 24-month statistics

Overview

Photonics Industries’ DM2 Series Dual Head Nd:YLF and Nd:YAG green nanosecond lasers combine remarkably high pulse energies (up to 200 mJ) or high average powers (up to 400 W) with a simple, rugged, and efficient form factor, all within a Dual Head configuration. Single head versions are available (see standard DM1 Series brochure). The proprietary resonator design[1] ideally fulfills the needs of both research and industry, from PIV research, to providing the necessary high energy for laser thermal processing or annealing applications in an industrial, compact form factor.
[1] US Patents #7,346,092 Diode side pumped high pulse energy Nd:YLF lasers, #7,082,149 High power diode side pumped solid state laser

DM Dual Head Series Nd:YLF & Nd:YAG Nanosecond Lasers Brochure

DX-266

Features

• 266nm Wavelength
• Compact, Rugged Design
• TEM00 Beam with M² < 1.3
• RS232 Computer Control
• External TTL Triggering
• Low Power Air-Cooled
• High Power Closed Loop Chiller

Please contact us for more information

SLM and NL options are available for many Photonics Industries lasers:

SLM with linewidth <100MHz or narrow linewidth(NL) ~3GHz in the fundamental.

Please contact us for more information

Features

• ns Pulse Width
• Narrow Bandwidth 1 to 3 GHz
• High repetition rate: single shot to 10kHz
• TEM00 Mode Beam Profile
• mJ level Energy/pulse
• Broad Tuning from 700 to 960nm
• Harmonic from 193 to 480nm
• External TTL Triggering
• Computer wavelength scanning (100MHz/step)
• Multi-pass Amplifiers to achieve ~ Watts level UV Output
• RS232 Computer Control

High pulse energy, 1mJ UV at 1kHz, 1.5mJ Green at 1kHz.

⤓ DC YLF Series Datasheet

Photonics Industries’ DC Series Nd:YLF Nanosecond Lasers combine ideal mJ pulse energy levels with high kHz repetition rates (single shot to 10 kHz), while maintaining short pulse widths, all within a compact, air-cooled form factor.

Features

• Industry-leading intracavity Nd:YLF technology for 30+ years
• Reliable, proven, all-in-one (AIO) air-cooled
• Ideal for FPD and high energy applications

⤓ DC YLF Series Datasheet

TEM₀₀ pulse energy: 35 mJ at 1 kHz, 527 nm.

⤓ DX YLF Series Datasheet

Features

• Highest pulse energy at 1kHz with TEM₀₀ beam mode commercially available
• Compact form factor for easy integration
• Industry-leading intracavity Nd:YLF technology for 30+ years

⤓ DX YLF Series Datasheet

Patented highest pulse energy green laser in the dual head regime: Up to 200 mJ, Nd:YLF; Up to 400 W, Nd:YAG

High Pulse Energy (Nd:YLF, 527nm)

DM2-527-20 | DM2-527-30 | DM2-527-40 | DM2-527-50 | DM2-527-60

DM2-527-100

High Power (Nd:YAG, 532nm)

DM2-532-60 | DM2-532-100 | DM2-532-150 | DM2-532-200

DM Dual Head Series Nd:YLF & Nd:YAG Nanosecond Lasers Brochure

Features

• Exceptional repetition rate control: Single shot up to 10 kHz, Nd:YLF; 1 to 50 kHz, Nd:YAG; Option up to 15 kHz available for Nd:YLF
• Excellent pulse stability: < 0.5% rms
• Proprietary Twin Pulse mode option for Quad Pulse in the Dual Head configuration: Generation of up to 4 pulses from a single trigger signal. Controllable pulse separation down to < 1 µs for Dual Head.
• TEM00 beam option available. Contact us.
• Unmatched reliability: < 1% service call requests within the warranty period in the latest 24-month statistics

Overview

Photonics Industries’ DM2 Series Dual Head Nd:YLF and Nd:YAG green nanosecond lasers combine remarkably high pulse energies (up to 200 mJ) or high average powers (up to 400 W) with a simple, rugged, and efficient form factor, all within a Dual Head configuration. Single head versions are available (see standard DM1 Series brochure). The proprietary resonator design[1] ideally fulfills the needs of both research and industry, from PIV research, to providing the necessary high energy for laser thermal processing or annealing applications in an industrial, compact form factor.
[1] US Patents #7,346,092 Diode side pumped high pulse energy Nd:YLF lasers, #7,082,149 High power diode side pumped solid state laser

DM Dual Head Series Nd:YLF & Nd:YAG Nanosecond Lasers Brochure

Features

• Diode pumped technology
• Patented OPO generation technology
• TEM00 beam
• Pulse rate from single shot to 50kHz
• mJ pulse energy at kHz repetition rates
• RS232 computer control
